ALLEN BRADLEY 1762-OW16 Used Working Digital Output

Product Overview

The Allen-Bradley 1762-OW16 (Series A, Revision A) is a high-density MicroLogix Expansion Relay Output Module, designed to provide additional switching capacity for MicroLogix 1100, 1200, and 1500 controller systems. This module features 16 independent relay outputs, allowing for the control of both AC and DC loads such as motor starters, solenoid valves, and indicator lights. As a Used Working unit, it offers a reliable and flexible solution for applications requiring dry-contact switching while maintaining a compact footprint on the expansion bus.

Key Features

• 16-Point Relay Outputs: Provides 16 discrete channels of electromechanical relay switching, supporting a wide range of voltages and current requirements.
• AC/DC Versatility: Capable of switching both 120/240V AC and 24V DC loads, making it a universal interface for diverse field devices.
• Isolated Grouping: Outputs are arranged in isolated groups, allowing for different voltages to be used across the same module (refer to wiring diagram for specific common groupings).
• Compact Modular Design: Easily integrates into the MicroLogix system via the built-in ribbon cable expansion bus, saving space in small control enclosures.
• Visual Diagnostics: Features clear front-panel LED indicators for each of the 16 output points, enabling rapid on-site troubleshooting and status verification.
• Rugged Reliability: Built to industrial standards with high-quality relay components designed for millions of mechanical cycles.

Item Condition (Used Working)

• Functional Status: Used Working. This module has been professionally removed from an operational panel. Each of the 16 relay contacts has been tested for continuity and successful switching under a MicroLogix test environment.
• Physical State: Clean industrial condition. The expansion ribbon cable is flexible and free of frays. Terminal screws are functional and move freely.
• Technical Integrity: Series A, Revision A hardware. No signs of contact pitting or housing damage. The unit is ready for immediate deployment in your RSLogix 500 project.
• Note: Professional installation is recommended. Ensure that the total current draw of your connected loads does not exceed the maximum contact rating specified by Allen-Bradley.

Package Includes

1. 1 x Allen-Bradley 1762-OW16 MicroLogix 16-Point Relay Output Module
2. Integrated expansion bus ribbon cable
