ALLEN BRADLEY 1398-DDM-019X Used Working ULTRA 100/200 Servo Drive

Product Overview

The Allen-Bradley 1398-DDM-019X (Ultra 100) is a high-performance, digital Servo Drive engineered for precise motion control in demanding industrial applications. This compact, base-style drive is part of the Ultra 100 series, known for its versatility in handling various feedback types and its robust integration into high-speed automated systems. Rated for an output current of 15 Amps (Peak) and 7.5 Amps (Continuous), it is designed to drive brushless AC servo motors with exceptional accuracy. As a Used Working unit, it serves as a reliable replacement for legacy systems, maintaining seamless compatibility with the ULTRA Master configuration software.

Key Features

• Digital Motion Precision: Provides high-resolution velocity and position control, ensuring smooth motor performance even at low speeds.
• Flexible Feedback Support: Compatible with standard encoders and Hall-effect sensors, allowing for integration with a wide range of Allen-Bradley and third-party servo motors.
• Compact "Base" Design: Features a slim footprint that maximizes panel space and allows for straightforward mounting in high-density control cabinets.
• Advanced Tuning Capabilities: Supports digital PID loop tuning via software, enabling the drive to be perfectly matched to the specific mechanical load and inertia of your machine.
• Integrated Protection Circuitry: Built-in safeguards against overvoltage, undervoltage, motor short-circuits, and overtemperature conditions to protect both the drive and the motor.
• Selectable Operating Modes: Can be configured for Torque, Velocity, or Position control, providing the flexibility needed for applications ranging from simple spinning to complex indexing.
• RS-232/485 Serial Interface: Equipped with a dedicated serial port for rapid configuration, diagnostic monitoring, and real-time status updates via a PC.

Item Condition (Used Working)

• Functional Status: Used Working. This servo drive has been professionally bench-tested using a compatible Y-Series servo motor. The power stage is fully functional, and the logic board successfully communicates with ULTRA Master software.
• Physical State: Clean industrial condition. The internal heat sinks are clear of debris, and the terminal connectors are in good shape. The metal chassis shows minor signs of previous installation but remains structurally sound.
• Technical Integrity: Tested for stable DC bus voltage and encoder feedback continuity. The internal memory has been cleared of previous motion profiles and is ready for new parameter sets.
• Note: Professional installation and tuning are required. Ensure that the motor parameters are correctly entered into the drive's configuration before enabling the power stage to prevent motor damage.

Package Includes

1. 1 x Allen-Bradley 1398-DDM-019X Ultra 100 Servo Drive
